Road Bike Frames, Wheels & Components / Integrated handlebar with raise?
« on: September 05, 2026, 02:47:36 PM »
Hello
I'm looking for an integrated handlebar with a bit of raise. The steering tube of my bike is cut a bit too short, and I want to raise the handlebar with minimum 20, ideally 25-30mm.
Up to now, this seems to be the best contender
https://www.aliexpress.com/item/1005012825351497.html
because
- I have Shimano 105 mechanic, 12 speed, and this one allow for internal routing for 4 cables (two for brakes, two for shifters)
- It's a 20mm raise, 70mm reach, 110 drop, -7degrees. The small reach and small drop are a plus for me. I've found designs similar to Tavelo, with 25mm raise, but -10 degrees, 77mm reach, 123mm drops (for instance, XMCS) - the raise is basically almost canceled by the angle and the reach.
- I need an 9 cm stem, 38 cm top, and a bit of flare (3-4 cm)
Questions:
1. Any feedback about the handlebar that I've found? Any real experiences with this brand - YICHORD (sounds like a weird jazz chord to me
) ?
2. Can you propose me alternatives along the lines of what I need (ideally: integrated, 25-30 mm raise, -7 degrees, 70 reach, 110 drops, 3-4 cm flare, for a size 380/90mm, compatible with internal routing)?
Thank you all
I'm looking for an integrated handlebar with a bit of raise. The steering tube of my bike is cut a bit too short, and I want to raise the handlebar with minimum 20, ideally 25-30mm.
Up to now, this seems to be the best contender
https://www.aliexpress.com/item/1005012825351497.html
because
- I have Shimano 105 mechanic, 12 speed, and this one allow for internal routing for 4 cables (two for brakes, two for shifters)
- It's a 20mm raise, 70mm reach, 110 drop, -7degrees. The small reach and small drop are a plus for me. I've found designs similar to Tavelo, with 25mm raise, but -10 degrees, 77mm reach, 123mm drops (for instance, XMCS) - the raise is basically almost canceled by the angle and the reach.
- I need an 9 cm stem, 38 cm top, and a bit of flare (3-4 cm)
Questions:
1. Any feedback about the handlebar that I've found? Any real experiences with this brand - YICHORD (sounds like a weird jazz chord to me
) ?2. Can you propose me alternatives along the lines of what I need (ideally: integrated, 25-30 mm raise, -7 degrees, 70 reach, 110 drops, 3-4 cm flare, for a size 380/90mm, compatible with internal routing)?
Thank you all
